DVI AOC

Description

RICHOOW DVI active optical cable is a high-performance, low power consumption, and low-cost optical fiber connectivity product, launched by RICHOOW CORPORATION LTD. The cable is a hybrid active optical cable, composed of four multimode fiber and seven copper cables. The multimode fiber is mainly to transmit high-speed data signals and can directly transmit high resolution, lossless a/v signal directly, instead of the traditional high-loss, high-latency, and RF-interference copper wires. RICHOOW DVI active optical cable is a plug-and-play product that does not require external power supply. Compared to copper cables, RICHOOW DVI active optical cable is thinner, softer, lighter, higher resolution, no radiation, and better compatibility.

Features

• High speed fiber optics
• Advanced optical engine
• Hot pluggable
• No external power supply required
• Low power consumption
• Long distance extension without signal loss
• EMI & RFI resistance
• Soft, thin and flexible


Parameters
Performance
StandardDVI
Data rate4.95Gbps
Color depth8-bit
Video Resolution1080p/1080i/720p
Interface
Source/Display24+1 DVI-D
Materialsnickel-copper
Optical Engine
Optical Engine TX/RXpatented optical engine assembly
Cable
Structure4*fiber+7*copper core
FiberOM3 multimode fiber
Copper Core30AWG*2+28AWG*3+24AWG*2
Length available1-300 meter
JacketPVC
ColorBlack
Cable Diameter4.8mm±0.1mm
WeightUp to length
Min. Bend Radius20mm
Max. Tensile Load245N
Environment
Working Temperature0℃~+70℃
Storage Temperature-20℃~+80℃
Power
Voltage+5V
Power Consumption≤250mW
Packaging
1-30meterKraft paper box
Lengths over 30meterRoll
More packaging listdust cover、wire net、cable tie, etc.
